Hemi Metals, a top-notch manufacturer and supplier located in Hamilton, New Zealand, specializes in Alloy 20 Round Bars that are crafted for outstanding corrosion resistance, strength, and durability in tough industrial settings. These bars are well-regarded for their remarkable ability to withstand both oxidizing and reducing acids, and they are produced under rigorous quality standards to guarantee consistent mechanical performance and precise dimensions. Hemi Metals is committed to ensuring that each Alloy 20 Round Bar provides dependable service and long-lasting performance. Their impressive chemical stability and toughness make them perfect for applications in chemical processing, marine environments, and high-performance engineering, serving both local and global markets.
Alloy 20 Round Bars from Hemi Metals are made from a nickel-chromium-molybdenum steel blend, featuring around 32–38% nickel, 19–21% chromium, 2–3% molybdenum, and trace amounts of copper to enhance corrosion resistance. In terms of mechanical properties, Alloy 20 boasts high tensile and yield strength, excellent toughness, and good ductility. It stands up well under stress and in harsh chemical conditions, including both oxidizing and reducing acids. The material’s stability at higher temperatures, along with its strong fatigue and wear resistance, ensures it remains durable. These characteristics make Alloy 20 Round Bars perfect for critical applications that demand both mechanical performance and chemical resilience.
Alloy 20 Round Bar Specification : ASTM B473 , ASME SB473
Dimension Standard : EN, DIN, JIS, ASTM, BS, ASME, AISI
Size : 14mm-300mm
Thickness : 50 mm to 6000 mm Long
Length : 1 To 6 Meters, Custom Cut Length
Form : Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc.
| Grade | C | Mn | Si | S | Cu | Ni | Cr | Fe | Mo | P |
|---|---|---|---|---|---|---|---|---|---|---|
| Alloy 20 | 0.07 max | 2.00 max | 1.00 max | 0.035 max | 3.00 – 4.00 | 32.00 – 38.00 | 19.00 – 21.00 | 29.85 min* | 2.00 – 3.00 | 0.045 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Alloy 20 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi – 35,000, MPa – 241 | 30 % |
| STANDARD | UNS | WNR. | EN | AFNOR |
|---|---|---|---|---|
| Alloy 20 | N08020 | 2.4660 | NiCr20CuMo | Z2NCUD31-20AZ |
Type | SIZES (mm) | ISO Tolerance | SIZES (Inches) |
|---|---|---|---|
Peeled and Polished | 40.00 to 150.00 | h11-DIN 1013 | 1.50″ to 6.00″ |
Cold Drawn and Ground | 10.00 to 75.00 | h9-h8-h11-h10 | 5/6″ to 2.50″ |
Cold Drawn and Polish | 3.00 to 75.00 | h9-h8-h11-h10 | 1/8″ to 3.00″ |
Peeled and Ground | 20.00 to 50.00 | h10-h9-h11 | 3/4″ to 2.00″ |
Cut to size on request (tolerance +2/-0 mm). Standard lengths of Alloy 20 Bars 2000 mm up to 6000 mm available
50.0 | 6.0 |
65.0 | 9.0 |
55.0 | 7.0 |
45.0 | 5.0 |
70.0 | 10.0 |
60.0 | 8.0 |
75.0 | 12.0 |
90.0 | 20.0 |
80.0 | 16.0 |
130.0 | 30.0 |
100.0 | 25.0 |
160.0 | 35.0 |
120.0 | 40.0 |
Choose the right Alloy 20 Round Bar based on factors like corrosion resistance, strength requirements, and compatibility with your specific application environment.
The pressure rating of Alloy 20 Round Bar depends on factors such as size, temperature, and specific application conditions, typically determined through engineering calculations.
Yes, Alloy 20 Round Bar can be welded, offering excellent weldability with proper techniques.
Hemi Metals’ Alloy 20 Round Bars find extensive use in industries that require exceptional corrosion resistance and mechanical reliability. They are commonly utilized in chemical processing equipment, pumps, valves, heat exchangers, and pressure vessels that come into contact with sulfuric acid and other aggressive substances. Additionally, these bars are employed in marine hardware, pharmaceutical processing equipment, and specialized industrial machinery where both strength and chemical resistance are essential.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
