Hemi Metals, based in Hamilton New Zealand is a leading provider of high-quality metal solutions designed to meet diverse industrial needs. Our Titanium Square Bars are expertly manufactured to deliver exceptional strength, corrosion resistance, and lightweight properties. These bars are available in various grades and dimensions, catering to industries. Such as aerospace, marine, chemical processing, automotive, and medical. Known for their durability and versatility, Titanium Square Bars from us are ideal for both structural and high-performance applications. With a commitment to precision and quality. We ensure that every product meets the stringent requirements of demanding environments, making us a trusted choice for titanium products worldwide.
Titanium Square Bars describe a solid piece of titanium that gives special qualities of strength, lightness, and great resistance to corrosion with a square cross-section. It is applicable in the industries of aerospace, marine, chemical processing, automotive, and medical fields for all applications that need durability and performance in severe conditions. Aspects of composition of titanium square bars differ by grades; pure commercial titanium (grade 2) consists of about 99% titanium, making it highly corrosive resistant, while alloyed grades such as grade 5 (Ti-6Al-4V) contain around 90% titanium, 6% aluminum, and 4% vanadium-alloying strength and versatility for very demanding structural and special applications.
| Standard | ASTM B348/ASME SB348, ASTMF67, ASTM F136, ISO-5832-2(3), AMS4928, MIL-T-9047G, JIS etc |
| Grade | TA1-TA4, TA7-TA10, TA15-TA18, GR1-GR5, GR6,GR7, GR9, GR11, GR12, TI-6AL-4V, TI-6AL-4VELI,GR23 |
| Diameter | 5-350mm |
| Length | Max6000mm |
| Technique | Forging ,Machining |
| Surface | acid surface or polishing, sand blasted surface |
| Shape | Square |
| Application | Metallurgy, electronics, medical, chemical, petroleum, pharmaceutical, aerospace, etc. |
Hardness, Brinell | 120 | 120 | annealed |
Hardness, Knoop | 132 | 132 | Estimated from Brinell. |
Hardness, Rockwell B | 70 | 70 | annealed |
Hardness, Vickers | 122 | 122 | Estimated from Brinell |
Tensile Strength, Ultimate | 240 MPa | 34800 psi | – |
Tensile Strength, Yield | 170 – 310 MPa | 24700 – 45000 psi | – |
Elongation at Break | 24 % | 24 % | – |
Reduction of Area | 35 % | 35 % | – |
Modulus of Elasticity | 105 GPa | 15200 ksi | In Tension |
Compressive Modulus | 110 GPa | 16000 ksi | – |
Poisson’s Ratio | 0.37 | 0.37 | – |
Charpy Impact | 310 J | 229 ft-lb | V-notch |
Shear Modulus | 45 GPa | 6530 ksi | – |
|
Physical Properties |
Metric |
English |
|
Density |
4.51 g/cc |
0.163 lb/in³ |
| Physical Properties | Metric | English |
|---|---|---|
| Density | 4.51 g/cc | 0.163 lb/in³ |
|
STANDARD |
WERKSTOFF NR. |
UNS |
|
Titanium |
3.7035 / 3.7165 / 3.7235 |
R50400 / R56400 / R52400 |
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@hemimetals.co.nz
Titanium Square Bars offer exceptional strength, lightweight properties, and corrosion resistance, making them ideal for high-performance applications in aerospace, medical, and industrial sectors.
Titanium Square Bars maintain excellent strength and stability even at elevated temperatures, making them suitable for use in extreme environments like aerospace engines and high-temperature industrial processes.
These Titanium Square Bars being very strong, corrosion-resistant, lightweight, and manifesting other such properties, are widely and largely used by industries. For example, in the aerospace industry, it is used for parts of structures, fasteners, and engines. Other common users include the marine industry-hence, utilized in the construction of ships and offshore platforms, as well as desalination plants because of their specific resistance to seawater. They extend into the medical field for applications such as implants, prosthetics, and surgical instruments. In the chemical processing industry, they are used to manufacture instruments such as heat exchangers, valves, and reactors. They also serve to solve high-performance applications in the automotive, defense, and energy sectors requiring high durability and reliability.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hemi Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Hamilton New Zealand
