Hemi Metals is a top-notch manufacturer and supplier located in Hamilton, New Zealand, specializing in high-quality Aluminium 1050 Forgings tailored for industrial and engineering needs. With a keen emphasis on precision, durability, and customization, the company provides components that adhere to both local and international standards. Aluminium 1050 is celebrated for its remarkable purity, resistance to corrosion, and ease of workability, making it perfect for crafting complex and lightweight forged parts. Hemi Metals caters to a variety of sectors, including automotive, electrical, marine, and construction, by offering bespoke forging solutions that ensure reliability, strength, and long-lasting performance even in tough conditions.
Aluminium 1050 Forgings are composed of at least 99.5% aluminum, with minor amounts of iron, silicon, copper, zinc, and manganese. This high-purity aluminum grade boasts excellent corrosion resistance along with impressive electrical and thermal conductivity. It showcases remarkable ductility and can be easily forged due to its softer nature. Typical mechanical properties include tensile strength ranging from 60 to 100 MPa, elongation between 25–35%, and low hardness, making it easy to form without cracking. Its lightweight quality and non-magnetic properties further enhance its appeal for specialized applications.
Temper : H14
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Alloy (ISS) | Equivalent alloy (A.A) | Copper | Magnesium | Silicon | Iron | Managanese Others* (Total) | Remarks | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Old | New | U.S.A | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Max | Max. | Aluminum 99.0% Min. | ||
| 1 B | 19500 | 1050 | — | 0.05 | — | — | — | 0.30 | 0.4 | — | 0.05 | 0.1 | Aluminum 99.5% Min. | ||
| Alloy | Temper | UTS (Mpa) | Yield Strength (Mpa) | Elongation (%) | ||
|---|---|---|---|---|---|---|
| Minimum | Maximum | Minimum | Maximum | A 50mm (Minimum) | ||
| EN AW-1050 A | F | 60 | – | 20 | – | 23 |
| O | 60 | 95 | 20 | – | 23 | |
| European Standard | BS (OLD) | USA (AA) | GERMANY (DIN) | ISO | IS | Canadian |
|---|---|---|---|---|---|---|
| EN AW-1050 A | 1E | 1050 | Al99.5 | Al99.5 | 19500, 19501 | 1 S |
Yes, Aluminum 1050 forgings can be shaped into custom designs through processes like open-die and closed-die forging, allowing for precise, unique shapes tailored to specific applications.
The ideal temperature range for forging Aluminium 1050 forgings is between 350°C to 500°C (660°F to 930°F), ensuring optimal material flow and minimizing the risk of cracking or deformation.
Aluminium 1050 Forgings find extensive use in industries where lightweight performance, superior ductility, and corrosion resistance are crucial. These forgings are perfect for electrical components like bus bars, connectors, and conductive fittings due to their outstanding electrical conductivity. In the automotive and transport sectors, they are utilized for lightweight brackets, assembled body parts, and structural components. The marine industry also benefits from these forgings, as they provide reliable solutions for various applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
