Located in the heart of Hamilton, Hemi Metals is a trusted local source for precision-engineered aluminium products. We take pride in supplying the industrial and creative sectors across New Zealand with top-quality materials, and our Aluminium 6061 Bar/Rods are a cornerstone of our offering. Known for their exceptional versatility and reliability, these bars are the go-to choice for fabricators and engineers who require a material that consistently performs under pressure, making them ideal for a huge range of demanding projects right here in our community.
The strength of Aluminium 6061 stems from its sophisticated blend of magnesium and silicon, which gives it excellent mechanical properties. This alloy is highly regarded for its solid tensile strength and good toughness, offering a great balance between being workable and durable. It responds wonderfully to heat treatment, which further enhances its capabilities, and it maintains good corrosion resistance. Essentially, it provides a robust yet manageable material that can be machined, welded, and fabricated with relative ease to meet precise specifications.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Mn | Si | Cr | Cu | Fe | Zn | Al | Mg | Ti | Other Each/Total |
| 0.15 | 0.4-0.8 | 0.15-0.35 | 0.15-0.4 | 0.7 | 0.25 | Remainder | 0.8-1.2 | 0.15 | 0.005/0.15 |
| Tensile Strengtd (PSI) | Yield Strengtd (PSI) | Shear Strengtd (PSI) | Elongation in 2″ | Brinell Hardness |
| 45,000 | 40,000 | 31,000 | 12 | 95 |
| UNS | EN | DIN | ISO | BS (OLD) | USA | WNR |
| A96061 | AW-AlMg1SiCu EN AW-6061 | AlMgSiCu | AlMg1SiCu | HE20 | AA6061 | 3.3211 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 6061 rods can be customized in size and length according to specific requirements. Manufacturers offer tailored solutions to meet the precise needs of various applications and industries.
To maintain Aluminium 6061 bars, regularly clean with mild soap and water, avoid harsh chemicals, inspect for damage, and store in dry, cool conditions to prevent corrosion and surface wear.
Yes, Aluminium 6061 bars are highly recyclable. Recycling this material preserves its properties, reduces energy consumption, and minimizes environmental impact, making it an eco-friendly choice for various industries.
The uses for 6061 Bar/Rods are practically endless, which is why they are such a popular choice. You’ll find them forming the sturdy frames of aerospace components, high-performance automotive parts, and robust marine fittings. They are equally at home in architectural structures, creating everything from decorative railings to strong structural supports. DIY enthusiasts and professional workshops alike value them for crafting custom jigs, frames, and functional prototypes. This adaptability makes 6061 an indispensable material for turning ambitious designs into solid, real-world solutions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
