Hemi Metals proudly stands as a trusted manufacturer and supplier right here in Hamilton, New Zealand, bringing top-tier materials to our local and international partners. Our focus on quality shines through with products like our Aluminium 6082 BarRods, a superb choice known for its strength and adaptability. We understand the needs of our customers, and we’re committed to delivering this versatile alloy with the reliability and service that our Kiwi reputation is built on, ensuring you have the right material to bring your projects to life.
This particular alloy has an excellent balance of qualities, making it a go-to material for many engineers. Its composition includes magnesium and silicon, which gives it very good mechanical properties. This combination results in a material that offers high strength, impressive toughness, and outstanding corrosion resistance. It also responds very well to heat treatment, allowing its properties to be finely tuned. Essentially, you get a bar that is strong enough for demanding applications but also easy to work with using various fabrication techniques.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Weight% | Al | Si | Fe | Cu | Mn | Cr | Mg | Zn | Ti | Other Each | Others Total |
| Aluminium 6082 | Bal | 0.7 – 1.3 | 0.50 max | 0.10 max | 0.40-1.00 | 0.25 max | 0.06-1.20 | 0.20 max | 0.10 max | 0.05 max | 0.15 max |
| Diameter or minor sectional dimension mm | Tensile Strength, MPa | Yield Strength 0.2%, MPa | Elongation % |
| 0-20 | 295 | 255 | 8 |
| 20-150 | 310 | 270 | 8 |
| 150-200 | 280 | 240 | 5 |
| UNS | EN | DIN | ISO | BS (OLD) | USA | WNR |
| A96082 | AW-6082 | AlMgSi1 | Al Si1MgMn | HE30 | AA6082 | 3.2315 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 6082 rods can be customized in size and length based on specific requirements. Manufacturers often offer custom dimensions to suit various industrial and structural applications.
Yes, Aluminium 6082 bars can be used underground due to their corrosion resistance and strength. However, proper coatings or anodization may be needed to enhance durability in highly corrosive environments.
Yes, Aluminium 6082 bars are fully recyclable. Aluminium is highly sustainable, retaining its properties through multiple recycling processes, making it an eco-friendly material for various applications.
Thanks to its impressive strength-to-weight ratio and adaptability, the applications for Aluminium 6082 BarRods are incredibly wide-ranging. You’ll often find it as the backbone in major structural frameworks for bridges and buildings, as well as in the robust chassis of trucks and trailers. It’s equally at home in the marine industry for boat building and in architectural projects for things like window frames and railings. From heavy-duty machinery parts to custom DIY projects, this alloy provides a reliable and durable solution that can handle significant stress and harsh environments with ease.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
